QUICK REFERENCE
41
Utility key (3/9)
Function
Save All
Gray
Portrait
(Printer only)
5 ~ 75
(Printer only)
Color Portrait/
Gray Portrait
SaveImage/
SaveAll/ Printer
Previous
Menu
On/ Off
Ink Saver
Off
Ratio
50%
Utility
F 1
F 2
F 3
F 4
F 5
H-COPY
Hardcopy
Hardcopy
Select Hardcopy function
F1
Turn Ink Saver On/Off
F2
Select printout color (only in
printout mode)
F3
Select printout ratio (only in
printout mode)
F4
Run Hardcopy
Hardcopy
Utility key (4/9)
Type
RS232
Previous
Menu
(RS232C only)
2400/ 4800/ 9600/
19200/ 38400
Baud Rate
9600
Stop Bit
2
(RS232C only)
Odd/ Even/ None
Parity
None
(RS232C only)
1/ 2
RS232/ USB/ GPIB
(GPIB only)
1 ~ 30
Address
1
F 1
F 2
F 3
F 4
F 5
F 2
Utility
Interface
Select interface
F1
Select GPIB address
F2→VAR
Select RS-232C baud rate
F2
Select RS-232C stop bit
F3
Select RS-232C parity
F4
