FAQ

161

• I pressed the Power (On/Standby) key on the front panel but nothing

happens.

• I connected the signal but it does not appear on the display.
• I want to remove the (Measurement result / FFT result / Help

contents) from the display.

• The waveform does not update (frozen).
• The probe waveform is distorted.
• Auto Set does not catch the signal well.
• I want to clean up the cluttered panel settings.
• The display image printout is too dark on the background.
• I want to install the optional battery pack.

I put the battery pack in but it is not working.

• The date and time setting are not correct.
• USB does not work.
• The accuracy does not match the specification.

I pressed the Power (On/Standby) key on the front panel
but nothing happens.

Make sure you turned On the rear panel Power switch. For power
up sequence, see page23.

I connected the signal but it does not appear on the display.

Make sure you have activated the channel by pressing the Channel
key (the LED turns On).
