GDS-2000 Series User Manual

10

G

ETTING STARTED

This chapter describes GDS-2000 in a nutshell,
including its main features and front / rear panel
introduction. After going through the overview,
follow the Set Up section to properly set up
operation environment.

GDS-2000 series
overview

Series lineup ...................................................11
Main Features ..................................................12
Package Contents ............................................13

Appearance

GDS-2064/2104/2204 Front Panel ....................14
GDS-2062/2102/2202 Front Panel ....................14
Rear Panel .......................................................18
Display ............................................................20

Set Up

Tilt stand .........................................................22
Power up .........................................................23
First Time Use .................................................24
