GDS-2000 Series User Manual

124

4. Use the Variable knob to

move the cursor. Press F1
(Select) to go into the folder
or go back to the previous
directory level.

Select

F 1

Go back to the root directory

Go back to the previous
(higher) directory

Go into the folder

Create new folder
/ Rename file or
folder

1. Move the cursor to the file

or folder location and press
F2 (New Folder) or F3
(Rename). The file/folder
name and the character map
appear on the display.

Rename

F 3

New

Folder

F 2

2. Use the Variable knob to

move the pointer to the
characters. Press F1 (Enter
Character) to add a
character or F2 (Back Space)
to delete a character.

Enter

Character

F 1

Back

Space

F 2
