REMOTE CONTROL CONFIG

151

Configure RS-232C interface

RS-232C
configuration

Connector

DB-9, Male

Baud rate

2400, 4800, 9600, 19200, 38400

Parity

None, Odd, Even

Data

bit

8 (fixed)

Stop

bit

1, 2

Panel operation

1. Press the Utility key.

Utility

2. Press F2 (Interface Menu).

Interface

Menu

F 2

3. Press F1 (Type) repeatedly

to select RS-232C.

Type

RS232

F 1

4. The interface icon at the top

of the display changes into
RS-232C type.

5. To change the baud rate,

press F2 (Baud Rate)
repeatedly.

Baud Rate

9600

F 2

Range

2400, 4800, 9600, 19200, 38400

6. To change the stop bit, press

F3 (Stop Bit) repeatedly.

Stop Bit

2

F 3

Range

1, 2

7. Data bit is fixed at 8.

8. To change the parity, press

F4 (Parity) repeatedly.

Parity

None

F 4
