GDS-2000 Series User Manual

12

Main Features

Performance

High sampling rate: up to 1GS/S real-time,
25GS/s equivalent-time

Deep memory: 25k points record length

Minimum 10ns peak detection

Feature

Wide selection range: 60MHz to 200MHz
bandwidth, 2 or 4 channels

Powerful display: 5.6 in. color TFT, wide
viewing angle, 8x12 divisions waveform
support

Battery operation

Automatic measurements: maximum 27 types

FFT analysis

Triggers: Edge, Video, Pulse Width

Advanced Delay trigger (for 2CH model only)

Program and play mode

Color printout of display contents

Go-No Go test

Built-in Help

Interface

USB host port: front and rear panel, to printers
and storage devices

USB slave port, RS-232C port, GPIB port
(option): for remote control

USB slave port for PC software connection

Calibration output

Go-No Go output

External trigger input (for 2CH model only)
