SAVE/RECALL

137

Recall

File type/source/destination

Item

Source

Destination

Default panel
setup

Factory installed
setting

Current front panel

Reference
waveform

Internal memory: A ~D

Current front panel

Panel setup
(DSxxxx.set)

Internal memory: S1 ~
S20

External memory: USB

Current front panel

Waveform data
(DSxxxx.csv)

Internal memory: W1 ~
W20

External memory: USB

Reference waveform
A ~ D

Display image
(DSxxxx.bmp)

External memory: USB

Display

Recall default panel setting

Panel operation

1. Press the Save/Recall key.

Save/Recall

2. Press F1 (Default Setup).

The factory installed setting
is recalled and replaces the
current panel setting.

Default

Setup

F 1

Setting contents

The following is the default setting contents.
