GDS-2000 Series User Manual

150

Interface Configuration

Configure USB interface

USB
configuration

PC side connector

Type A, host

GDS-2000 side
connector

Type B, slave

Speed

1.1/2.0 (full speed)

Panel operation

1. Press the Utility key.

Utility

2. Press F2 (Interface Menu).

Interface

Menu

F 2

3. Press F1 (Type) repeatedly

to select USB.

Type

USB

F 1

4. The interface icon at the top

of the display changes into
USB type.

5. Connect the USB cable to

the rear panel slave port.

6. When the PC asks for the USB driver, select

gds2k_cdc.inf included in the FreeWave
software package downloadable from GW
website,

www.gwinstek.com

, GDS-2000

product corner. The driver file automatically
sets GDS-2000 as serial port COM7.
