GDS-2000 Series User Manual
138
Acquisition Mode: Normal Memory length: 500
Channel Scale: 2V/Div CH1: On, CH2/3/4: Off
Coupling: DC Invert: Off
BW limit: Off Probe attenuation: x1
Cursor Source: CH1 Horizontal: None
Vertical: None
Display Type: Dots Accumulate: Off
Graticule:
Go-NoGo Go-No: Off Source: CH1
NoGo when: Violating: Stop
Horizontal Scale: 2.5us/Div Mode: Main Timebase
Math Type: + (Add) Channel: CH1+CH2
Position: 0.00 Div Unit/Div: 2V
Measure Source1, 2: CH1, CH2 Type: VPP, Freq, FRR
Program Mode: Edit Step: 1
Trigger Type: Edge Source: Channel1
Mode: Auto Slope:
Coupling: DC Rejection: Off
Noise Rejection: Off
Utility SaveImage, InkSaver Off GPIB, Address 8
Sound: Off
