GDS-2000 Series User Manual

162

I want to remove the (Measurement result / FFT result /
Help contents) from the display.

To clear automatic measurement result, press the Measure key
twice, then Press F4 (OFF). See page55 for details.
To clear FFT result, press the Math key twice. See page64 for details.
To clear Help result, press the Help key again. See page46 for
details.

The waveform does not update (frozen).

Press the Run/Stop key to unfreeze the waveform. See page50 for
details.
If this does not help, the trigger mode might be set to Single. Press
the Trigger menu key, then F3 (Mode) to Auto. See page106 for
trigger setting details.

The probe waveform is distorted.

You might need to compensate the probe. For details, see page159.
Note that the frequency accuracy and duty factor are not specified
for probe compensation waveform and therefore it should not be
used for other reference purpose.

Auto Set does not catch the signal well.

Autoset function cannot catch signals under 30mV or 30Hz. Please
use the manual operation. See page49 for Auto Set details.

I want to clean up the cluttered panel settings.

Recall the default settings by pressing Save/Recall key→F1. For
default setting contents, see page45.
