GDS-1000-U Series User Manual

96

S

AVE/RECALL

The save function allows saving display images,
waveform data, and panel settings into the
oscilloscope’s internal memory or to the front
panel USB port. The recall function allows
recalling the default factory settings, waveform
data, and panel settings from the oscilloscope’s
internal memory or from USB.

File Structures

Three types of file are available: display image, waveform file, and
panel settings.

Display image file format

Format


Contents

The current display image in 234 x 320 pixels, color
mode. The background color can be inverted (Ink
saver function).

Waveform file format

Format

xxxx.csv (Comma-separated values format which
can be opened in spreadsheet applications such as
Microsoft Excel)

Waveform type

CH1, 2

Input channel signal

Math

Math operation result (page 5858)

Storage location Internal

memory

The oscilloscope’s internal memory,
which can hold 15 waveforms.
