Display key, Autoset key, Hardcopy key – GW Instek GDS-1000-U Series User Manual User Manual
Page 27: Help key
QUICK REFERENCE
27
Display key
Vectors/ Dots
Type
Vectors
On/ Off
Accumulate
Off
Refresh
Contrast
Full
/ /
Display
Select waveform type
Type
Waveform accumulate On/Off
Accumulate
Refresh accumulation
Refresh
Set display contrast
Contrast →VAR
Select display grid
Autoset key
Autoset
Automatically find the signal and set the scale
Autoset
Hardcopy key
Hardcopy
→
See Utility key (page 38)
Help key
Help
Turn help mode on/off
Help
