GDS-1000-U Series User Manual

28

Horizontal menu key

Main

Window

Window

Zoom

XY

Roll

MENU

Select main (default) display

Main
Select window mode

Window →TIME/DIV

Zoom in window mode

Window Zoom
Select window roll mode

Roll
Select XY mode

XY

Math key 1/2 (+/-)

Operation

CH1+CH2

Position

0.00 Div

Unit/Div

2V

-12div ~ +12div

CH1+CH2
CH1-CH2
FFT

MATH

200mV~10V/div

Math on/off

Math

Select math operation type (+/–
/FFT)

Operation

Set result position

Position →VAR
Math result Volt/Div

Unit/Div→VAR
