Recalling a reference waveform to the display

Procedure

The reference waveform must be stored in
advance. See page 105 for details.

1. Press the Save/Recall key.

Save/Recall

2. Press Display Refs. The

reference waveform display
menu appears.

Display

Refs.

3. Select the reference

waveform, Ref A or Ref B,
and press it. The waveform
appears on the display and
the period and amplitude of
the waveform appears in the
menu.

Ref.A Off

Ref.A On

1V

2.5ms

4. To clear the waveform from

the display, press RefA/B
again.

Ref.A Off

Recalling panel settings

Procedure

1. (For recalling to USB) Insert

the USB flash drive into the
front panel USB port.

2. Press the Save/Recall key.

Save/Recall
