background image

SAVE/RECALL

101

Quick Save (HardCopy)

Background

The Hardcopy key works as a
shortcut to save display
images, waveform data, and
panel settings onto a USB flash
drive card.

Hardcopy

The Hardcopy key can be configured into two
types of operations: save image and save all
(image, waveform, setup).

Using the Save/Recall key can
also save files with more
options. For details, see page
103.

Save/Recall

Functionalities

Save image
(*.bmp)

Saves the current display image into
a USB flash drive.

Save all

Saves the following items into a USB
flash drive.

Current display image (*.bmp)

Current system settings (*.set)

Current waveform data (*.csv)

Procedure

1. Insert a USB flash drive into

the front panel USB port.

2. Press the Utility key.

Utility

3. Press Hardcopy Menu.

Hardcopy

Menu

4. Press Function repeatedly to

select Save Image or Save All.

Function

Save All
