GDS-1000-U Series User Manual
30
Measure key
Voltage
Vpp
Previous
Menu
Voltage/Time
Vpp
1:204mV
2: 300mV
Vavg
1: 1.93mV
2: 28.0mV
Frequency
1: 1.000kHz
2: 3.003kHz
Duty Cycle
1: 50.01%
2: 49.88%
Rise Time
1. 76.20us
2. 70.11us
Measure Measure
Turn on/off measurement
Measure
Select measurement type
Voltage/Time
Select measurement item
VAR or Icon(F3) / → VAR
Go back to previous menu Previous Menu
Run/Stop key
Run/Stop
Freeze/unfreeze waveform or trigger
Run/Stop
