GDS-1000-U Series User Manual
114
3. Press Recall Waveform. The
display shows the available
source and destination
options.
Recall
Waveform
4. Press Source repeatedly to
select the file source,
internal memory or USB.
Use the Variable knob to
change the memory location
(W1 ~ W15)/DSXXXX.CSV.
Source
Memory
VARIABLE
Memory Internal memory, W1 ~ W15
USB USB flash drive,
DSXXXX.CSV. The waveform
file(s) must be placed in the
root directory to be loaded.
5. Press Destination. Use the
Variable knob to select the
memory location. Destination
VARIABLE
RefA, B Internally stored reference
waveforms A, B
6. Press Recall to confirm
recalling. When completed,
a message appears at the
bottom of the display. Recall
Note
The file will not be recalled if the
power is turned off or the USB flash
drive is removed before completion.
