Trigger key 5/5
LF/ HF/ Off
On/ Off
/
Slope
Coupling
AC
Rejection
Off
Previous
Menu
Noise Rej
Off
AC/ DC
Coupling/Slope
Select trigger slope type
Slope
Select trigger coupling mode
Coupling
Select frequency rejection
Rejection
Turn noise rejection on/off
Noise Rej
Go back to previous menu
Previous Menu
Utility key 1/10 (Utility #1)
Hardcopy
Menu
More
ProbeComp
Menu
Language
English
To Probe
Comp menu
To Hardcopy
menu
English/
Chinese(T) etc
Utility
Utility #2 menu
System
Info.
Go to hardcopy menu
Hardcopy
Go to probe compensation menu
ProbeComp
Select language
Language
Show system information
System Info.
Go to the next Utility menu
More
