MEASUREMENT

61

Go No-Go Testing

Overview

Background

Go-NoGo testing checks if a waveform conforms to
a user-specified maximum and minimum
boundary (template). The testing can be set to stop
or continue each time the template has or has not
been violated by the input waveform.

Settings

Item

Default

Details

NoGo criteria: When inside
or outside the boundary

Inside

Page 62

Source

Channel 1 Page 62

Test continue or stop when
NoGo occurs

Stop

Page 63

Boundary (template) –
selects the minimum and
maximum boundaries
(template) from a single
waveform

Auto (0.4%) Page 63

Run Tests

Page 67
