GDS-1000-U Series User Manual

74

7. Press Normal.

Normal

8. Press Peak-Detect and see

that a spike noise is
captured.

Peak

Detect

Example

The peak detect mode reveals the occasional glitch.

Normal mode

Peak detect mode
