GDS-1000-U Series User Manual
126
Probe Specifications
GDS-1052-U & GDS-1072-U Probe
Applicable model &
probe GDS-1052-U, GDS-1072-U
GTP-070A-4
Position x 10 Attenuation Ratio 10:1
Bandwidth DC ~ 70MHz
Input Resistance 10MΩ when used with 1MΩ input
Input Capacitance 28~32pF approx.
Maximum Input
Voltage ≤600Vpk, Derating with frequency
Position x 1 Attenuation Ratio 1:1
Bandwidth DC ~ 6MHz
Input Resistance 1MΩ when used with 1MΩ input
Input Capacitance 120~220pF approx.
Maximum Input
Voltage ≤200Vpk, Derating with frequency
Operating Cond. Temperature –10°C ~ 50°C
Relative Humidity ≤85% @35°C
Safety Standard EN 61010-031 CAT II
