GDS-1000-U Series User Manual
26
Cursor key 1/2
CH1/ 2/ MATH
Source
CH1
X1
123.4us
212.0mV
X2
22.9us
0.000V
X 1 X 2
2 3 . 6 u s
1 1 . 9 H z
2 1 2 . 0 m V
X ↔Y
Cursor
Turn cursor on/off
Cursor
Move X1 cursor
X1→ VAR
Move X2 cursor
X2→ VAR
Move both X1 and X2 cursor
X1X2→ VAR
Switch to Y cursor
X↔Y
Cursor key 2/2
CH1/ 2/ MATH
Source
CH1
X ↔Y
Cursor
Y1
123.4mV
Y2
12.9mV
Y1Y2
1 0 . 5 m V
Turn cursor on/off
Cursor
Move Y1 cursor
Y1→ VAR
Move Y2 cursor
Y2→ VAR
Move both Y1 and Y2 cursor
Y1Y2→ VAR
Switch to X cursor
X↔Y
