GDS-1000-U Series User Manual

88

Range

Auto, Normal

5. Press Slope/coupling to enter

into the trigger slope and
coupling selection menu.

Slope /

Coupling

6. Press Slope repeatedly to

select the trigger slope,
rising or falling edge.

Slope

Range

Rising edge, falling edge

7. Press Coupling repeatedly to

select the trigger coupling,
DC or AC.

Coupling

AC

Range

DC, AC

8. Press Rejection to select the

frequency rejection mode.

Rejection

Off

Range

LF, HF, Off

9. Press Noise Rej to turn the

noise rejection on or off.

Noise Rej

Off

Range

On, Off

10. Press Previous menu to go

back to the previous menu.

Previous

Menu
