CONFIGURATION

91

7. Press Slope repeatedly to

select the trigger slope,
which also appears at the
bottom of the display.

Slope

Range

Rising edge, falling edge

8. Press Coupling repeatedly to

select the trigger coupling.

Coupling

AC

Range

DC, AC

9. Press Rejection to select the

frequency rejection mode.

Rejection

Off

Range

LF, HF, Off

10. Press Noise Rej to turn the

noise rejection on or off.

Noise Rej

Off

Range

On, Off

11. Press Previous menu to go

back to the previous menu.

Previous

Menu

Manually triggering the signal

Note

Note: This section describes how to manually
trigger the input signals when the oscilloscope
does not capture them. This section applies to the
Normal and Single trigger mode, since in the Auto
trigger mode, the oscilloscope keeps updating the
input signal regardless of the trigger conditions.
