I
NDEX
AC coupling ............................... 83
Accumulating waveform .......... 76
Acquisition ................................. 72
menu tree ....................................... 25
specification ................................. 124
Addition ..................................... 59
Amplitude measure .................. 52
auto set
faq.......................................... 119, 120
Auto set ....................................... 46
exception ........................................ 47
specification ................................. 125
Auto trigger ................................ 85
Automatic measurement .......... 54
menu tree ....................................... 30
overview ........................................ 52
specification ................................. 125
Average acquisition .................. 73
Average voltage measure ......... 53
Bandwidth limitation ................ 83
Blackman window ..................... 58
Calibration
menu tree ....................................... 40
Calibration, vertical resolution
............................................... 116
Caution symbol............................ 8
Channel ....................................... 45
faq.................................................. 119
menu tree ....................................... 25
Cleaning the instrument ........... 10
configure remote control .......... 93
Coupling mode .......................... 82
menu tree ....................................... 25
cursor
horizontal operation .................... 55
Cursor ......................................... 55
faq.................................................. 119
menu tree ....................................... 26
specification ................................. 125
Cycle time measure ................... 53
Data logging
menu tree ....................................... 42
overview ........................................ 68
run ................................................... 71
setup ............................................... 69
source ............................................. 69
DC coupling ............................... 82
Declaration of conformity ....... 129
Default setup ............................ 111
contents .......................................... 43
menu tree ....................................... 31
Display ........................................ 77
contrast setting .............................. 77
diagram .......................................... 20
grid setting ..................................... 77
menu tree ....................................... 27
specification ................................. 125
Display image
faq ................................................. 120
file format ...................................... 96
save ............................................... 106
save menu tree .............................. 34
Disposal instructions ................. 11
Dot waveform ............................ 76
Duty cycle measure ................... 53
Edge trigger ................................ 87
menu tree ....................................... 37
EN61010
measurement category .................. 9
pollution degree ........................... 11
Environment ............................. 125
safety instructions ........................ 10
equivalent time sampling ......... 75
External trigger .......................... 85
input terminal ............................... 17
