MEASUREMENT
63
Edit: NoGo Violation Conditions
Procedure 1. Press the Utility key. Utility
2. Press the More key.
More
3. Press the Go-NoGo Menu
key.
Go-NoGo
Menu
4. Press Violating repeatedly
to select the NoGo
conditions.
Violating
Stop
Stop Stops the test when the NoGo
conditions have been met.
Continue The tests continue even when the
NoGo conditions have been met.
Edit: Template (boundary)
Background The NoGo template sets the upper and lower
amplitude boundary. Two methods are available:
Min/Max and Auto.
Min/Max Selects the upper boundary (Max)
and lower boundary (Min) as
separate waveforms, from the
internal memory. The upper
boundary is saved to Ref A, the
lower boundary is saved to Ref. B.
Advantage: The template shape
and distance (allowance) between
the source signal are fully
