D3-20
IM 01W02D01-01EN
• Add a field wireless subnet
When the [Add] button is clicked, the window shown in Figure D3-18 appears.
FD0318.ai
Figure D3-18 Add Field Wireless Subnet Window
When the [Network ID] field is entered and the [OK] button is clicked, it is added to the list in the
main window and under [Field Wireless Networks] in the menu tree.
The Network ID setting range is a decimal number between 2 and 65535.
• Delete a field wireless subnet
When the [Delete] button in the main window is clicked, the dialog shown in Figure D3-19
appears.
FD0319.ai
Figure D3-19 Warning Dialog
When the [OK] button in the dialog shown in Figure D3-19 is clicked, the respective network
ID and all data related to this subnet are deleted.
