D3-19
IM 01W02D01-01EN
D3.2.4 Field Wireless Networks
When [Field Wireless Networks] is selected in the menu tree of the Configurator, the tab shown in
Figure D3-17 appears in the main window.
FD0317.ai
Figure D3-17 Field Wireless Network Setting Tab
At this tab, configure the settings of the field wireless subnets connected under the YFGW410.
The default setting is to register a field wireless subnet with a Network ID of 100. When the net-
work ID of the field wireless subnet is registered here, Network ID:100 (when the default setting is
used) appears under [Field Wireless Networks] in the menu tree of the window.
Button name Function
Add When this button is clicked, the window shown in Figure D3-18 appears.
Delete
When a Network ID to be deleted is selected and this button is clicked, the dialog shown
in Figure D3-19 appears.
