D3. Constructing a Field Wireless
System
This chapter describes the procedure to construct a Field Wireless System.
Before starting, finish provisioning all field wireless devices that will join the field wireless network
and prepare a provisioning information file. For details about the provisioning procedure, see the
FieldMate User‘s Manual (IM 01R01A01-01E).
D3.1 Setting Operation Items
To construct a wireless network, use the Field Wireless Management Console to start the Con-
figurator and configure the following settings.
Tree pane item names
Operation overview
n
YFGW410 Settings
Set the device tag of the YFGW410 and the Layer2 switch of the Field Wire-
less Backbone Network during YFGW410 redundant operation
• Interfaces
Set the IP addresses of the Field Wireless Backbone Network and mainte-
nance interface, and set use of field networks and their IP Addresses
• Access Control Lists
Register connections to the Access Control List of the ports of the YFGW410
• Time Source
Select the time synchronization method of the system
n
Operation Mode
Select the operation mode of the wireless network
n
Hopping Patterns
Set the transmission channels used by the field wireless subnet
n
Field Wireless Networks
Define the Network ID, hopping patterns, and their descriptions for the field
wireless subnet
• Network ID 100
Define the information of the field wireless subnet (when Network ID is 100),
register the Field Wireless Access Point that form the network, and register
field wireless devices
n
Graphic Editor
Configure the display of the wireless device arrangement visually as a floor
plan
n
Alert Settings
Set the tolerances to determine parameters warnings related to the wire-
less conditions displayed by the Monitor of the Field Wireless Management
Console
n
Sampling Settings
Set the parameters related to the update time, such as process values
n
Modbus Settings
Select the method of mapping to the Modbus register, such as process val-
ues, and mapping to the Input registers and Holding registers
n
Resource
Display the usage rate of the wireless band of each field wireless subnet
After configuring the settings for the field wireless network, download the settings to the
YFGW410, YFGW510, and field wireless devices.
