Stop Bits [1]

Use the Stop Bits option to specify the number of stop bits used to indicate the end of a

serial data packet. Communication with slow devices may require more than 1 stop bit.

1

D

EFAULT

Sets the number of stop bits at 1.

2

Sets the number of stop bits at 2.

5.4 Chipset

Use the Chipset menu (

630H

BIOS Menu 14) to access the PCH and System Agent (SA)

configuration menus.

WARNING!

Setting the wrong values for the Chipset BIOS selections in the Chipset

BIOS menu may cause the system to malfunction.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Main

Advanced

Chipset

Boot

Security Save & Exit


> PCH-IO Configuration
> System Agent (SA) Configuration


PCH Parameters


---------------------
: Select Screen

: Select Item

Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 14: Chipset
