Page 65

1010-1023, Rev 00

The following sections completely describe the configuration options found in the menu

items at the top of the BIOS screen and listed above.

5.2 Main

The Main BIOS menu (

616H

BIOS Menu 1) appears when the BIOS Setup program is

entered. The Main menu gives an overview of the basic system information.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Main

Advanced Chipset

Boot

Security Save & Exit

BIOS Information
BIOS Vendor

American Megatrends

Core Version

4.6.5.3

Compliancy

UEFI 2.3; PI 1.2

Project Version

E410AT13.ROM 0.18 x64

Build Date and Time

08/27/2012 11:46:29


Total Memory

4096 MB (DDR3)

System Date

[Tue 10/16/2012]

System Time

[14:20:27]

Access Level

Administrator


Set the Date. Use Tab to
switch between Data
elements.


----------------------

: Select Screen

: Select Item

Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 1: Main

BIOS Information

The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information

cannot be changed. The items shown in the system overview include:

BIOS Vendor: Installed BIOS vendor

Core Version: Current BIOS version

Compliancy: compliant UEFI specification version

Project Version: the board version

Build Date and Time: Date and time the current BIOS version was made
