Page 107 1010-1023, Rev 00
6.2.20 Touch Panel Connector (TOUCH1)
6.2.21 USB 2.0 Connectors (USB1/USB2/USB3/USB4)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
2 8
   
   
1 7
1 VCC 2 GND
3 DATA- 4 DATA+
5 DATA+ 6 DATA-
7 GND 8 VCC
Table 6-22: USB 2.0 Connector (USB1/USB2/USB3/USB4) Pinouts
6.3 External Interface Panel Connectors
The table below lists the rear panel connectors on the PC400C Series Panel PC
motherboard. Pinouts of these connectors can be found in the following sections.
Connector Type Label
Audio connector (line-out and mic-in) Audio jack AUDIO1
RJ-45 LAN connectors RJ-45 LAN1/2
Reset button Push button RST_SW1
PIN NO. 8-Wire 4-Wire 5-Wire
1 Right Sense N/A N/A
2 Left Sense N/A N/A
3 Bottom Sense N/A N/A
4 Top Sense N/A Sense (S)
5 Right Excite Right LR (X)
6 Left Excite Left LL (L)
7 Bottom Excite Bottom UR (Y)
8 Top Excite Top UL (Y)
9 GND GND GND
Table 6-21: Touch Panel Connector ( TOUCH1) Pinouts
