5.3.4 SATA Configuration

Use the SATA Configuration menu (

621H

BIOS Menu 6) to change and/or set the

configuration of the SATA devices installed in the system.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Advanced


SATA Controller(s)

[Enabled]

SATA Mode Selection

[IDE]

SATA1 Port

Empty

SATA2 Port

Empty

SATA3 Port

Empty

SATA4 Port

Empty


Enable or disable SATA
Device.


---------------------

: Select Screen

: Select Item

Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 6: SATA

Configuration

SATA Controller(s) [Enabled]

Use the SATA Controller(s) option to configure the SATA controller(s).

Enabled

D

EFAULT

Enables the on-board SATA controller(s).

Disabled

Disables the on-board SATA controller(s).

SATA Mode Selection [IDE]

Use the SATA Mode Selection option to configure SATA devices as normal IDE devices.

IDE

D

EFAULT

Configures SATA devices as normal IDE device.

AHCI

The SATA drive connected to the nth SATA drive port is

specified as a normal SATA drive.
