Page 53
1010-1023, Rev 00
4.1 System Maintenance Introduction
The following system components may require maintenance.
Motherboard
SO-DIMM module
PSU module
Cooling fans
If these components fail, they must be replaced. Please contact the system reseller or
vendor to purchase replacement parts. Replacement instructions for the above listed
components are described below.
4.2 Motherboard Replacement
The motherboard is not field-serviceable. If the motherboard fails, the unit must be
shipped back to Maple Systems to be replaced. Please contact your distributor or Maple
Systems for details.
4.3 Back Cover Removal
WARNING!
Before removing the back cover, make sure all power to the system
has been disconnected. Failing to do so may cause severe damage to
the PC400C Series Panel PC and injury to the user.
