Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan control [Auto Duty-Cycle Mode]
CPU Temperature 1 60
CPU Temperature 2 50
CPU Temperature 3 40
CPU Temperature 4 30
Duty Cycle 1 100
Duty Cycle 2 80
Duty Cycle 3 70
Duty Cycle 4 50
SYS_FAN2 Smart Fan control [Auto Duty-Cycle Mode]
System Temperature 1 60
System Temperature 2 50
System Temperature 3 40
System Temperature 4 30
Duty Cycle 1 90
Duty Cycle 2 60
Duty Cycle 3 40
Duty Cycle 4 10
SYS_FAN3 Smart Fan control [Auto Duty-Cycle Mode]
Temperature 1 70
Temperature 2 60
Temperature 3 50
Temperature 4 30
Duty Cycle 1 90
Duty Cycle 2 60
Duty Cycle 3 40
Duty Cycle 4 10
Smart Fan Mode Select
---------------------
: Select Screen
  : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: Smart Fan Mode Configuration
 CPU_FAN1/SYS_FAN2/SYS_FAN3 Smart Fan Control [Auto by RPM]
Use the CPU_FAN1/SYS_FAN2_SYS_FAN3 Smart Fan Control option to configure the
smart fans.

Manual Duty
Mode
The fan spins at the speed set in Manual Duty
Mode settings.

Auto
Duty-Cycle
Mode
D EFAULT The fan adjusts its speed using Auto Duty-Cycle
Mode settings.
