Page 69 1010-1023, Rev 00
Wake up minute
Wake up second
After setting the alarm, the computer turns itself on
from a suspend state when the alarm goes off.
5.3.3 CPU Configuration
Use the CPU Configuration menu (
619H
BIOS Menu 5) to view detailed CPU specifications
and configure the CPU.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Pentium(R) CPU G630T @ 2.30GHz
CPU Signature
206a7
Microcode Patch 25
Max CPU Speed 2300 MHz
Min CPU Speed 1600 MHz
CPU Speed 2300 MHz
Processor Cores 2
Intel HT Technology Not Supported
Intel VT-x Technology Supported
Intel SMX Technology Not Supported
64-bit Supported
L1 Data Cache
32 KB x 2
L1 Code Cache 32 KB x 2
L2 Cache 256 KB x 2
L3 Cache 3072 KB
Intel Virtualization Technology [Disabled]
When enabled, a VMM can
utilize the additional
hardware capabilities
provided by Vanderpool
Technology
----------------------
: Select Screen
  : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 5: CPU Configuration
The CPU Configuration menu (
620H
BIOS Menu 5) lists the following CPU details:
 CPU Signature: Lists the CPU signature value.
 Microcode Patch: Lists the microcode patch being used.
 Max CPU Speed: Lists the maximum CPU processing speed.
 Min CPU Speed: Lists the minimum CPU processing speed.
 CPU Speed: Lists the CPU processing speed.
 Processor Cores: Lists the number of the processor core
