Disabled

Legacy USB support disabled

Auto

Legacy USB support disabled if no USB devices are

connected

5.3.6 F81866 Super IO Configuration

Use the F81866 Super IO Configuration menu (

623H

BIOS Menu 8) to set or change the

configurations for the serial ports.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Advanced

F81866 Super IO Configuration

F81866 Super IO Chip

F81866

> Serial Port 1 Configuration
> Serial Port 2 Configuration
> Serial Port 3 Configuration
> Serial Port 4 Configuration
> Serial Port 5 Configuration


Set Parameters of Serial
Port 1 (COMA)


---------------------
: Select Screen

: Select Item

Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 8: F81866 Super IO Configuration
