14 pcie mini card slot (mini_pcie1), Table 6-14: lvds connector (lvds1) pinouts – Maple Systems PC419C User Manual
Page 116
1010-1023, Rev 00
Page 104
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
23
LVDSA7+
24
LVDSA7-
25
GND
26
GND
27
LCDVCC
28
LCDVCC
29
LCDVCC
30
LCDVCC
Table 6-14: LVDS Connector (LVDS1) Pinouts
6.2.14 PCIe Mini Card Slot (MINI_PCIE1)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
WAKE#
2
3.3 V
3
RESERVED
4
GND
5
RESERVED
6
1.5 V
7
CLKREQ#
8
N/C
9
GND
10
N/C
11
REFCLK-
12
N/C
13
REFCLK+
14
N/C
15
GND
16
N/C
17
N/C
18
GND
19
N/C
20
W_DISABLE#
21
GND
22
PERST#
23
PERn0
24
3.3VAUX
25
PERp0
26
GND
27
GND
28
1.5 V
29
GND
30
SMBCLK
31
PETn0
32
SMBDATA
33
PETp0
34
GND
35
GND
36
USBD-
37
RESERVED
38
USBD+
39
RESERVED
40
GND
41
RESERVED
42
LED_WWAN#
43
RESERVED
44
LED_WLAN#
45
RESERVED
46
LED_WPAN#
