Lincoln Electric IM10178 POWER FEED 84 U.I. CONTROL BOX - Manual (Page 99)

1 Case Front Blank G7501-2 1 X •
2 UI Case Front Assembly, Includes: G7613 1 • X
2A UI Case Front G7501 1 • X
2B Nameplate G7448 1 • X
2C Button Cover (Small) S23055-1 12 • X
2D Can Mem UI P.C. Board Assembly S29865 1 • X
2E Sems Screw T10082-12 4 • X
2F Shaft Seal (Not Shown) T14034-4 2 • X
2G Knob (1”) M22778-1 3 • X
2H- Thread Forming Screw S9225-99 4 X X
3 UI Trim G6529-1 1 X X
Jan-14
POWER FEED ® 84 DuAL
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-746-C.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-746-C.1
