B-10

OPERATION

Trigger selecTion

To select the trigger type, press the right button until the trigger
LED illuminates.

Rotate the center knob clockwise for 4-step trigger or counter-
clockwise for 2-step trigger.

Note that different trigger types may be stored in the memories.
For example, memory 1 may use a 2-step trigger and memory 3
may use a 4-step trigger.

When using A-B Dual Procedure, both A and B procedures must
be the same trigger type.

POWER FEED 84, POWER FEED 84 DUAL

2-Step Trigger
