B-34

OPERATION

POWER FEED 84, POWER FEED 84 DUAL

Parameter

Name and Description

P.106

View Ethernet IP Address

Used for viewing the IP address of Ethernet compatible equipment.
Press the Right Button to read the IP Address.
Press the Left Button to back out and exit this option. The IP address cannot be changed
using this option.

P.107

View Power Source Protocol

Usedforviewingthetypeofpowersourcethefeederisconnectedto.
Press the Right Button to identify the power source as either LincNet or ArcLink.
PresstheLeftButtontobackoutandexitthisoption.

P.350

User Interface Group Selection

Used to differentiate multiple feeders connected to the same power source. Each
independentfeedermusthaveauniqueselectioninordertoresolveerror18prob-
lems.

P.500

View Lockout Parameters

Originallyusedtopreventinadvertentchangesofsecuresetupparameters,P.500
waspreviouslyusedasagatewaytotheseparameters.Presently,thisoptiondoes
notexistinanysetupmenu.

P.501

Encoder Lockout

Locks one or both of the upper knobs (encoders), preventing the operator from
changing wire feed speed, amps, volts or trim. The function of each upper knob
dependsontheselectedweldmode.Whenaconstantcurrentweldmodeisselect-
ed(e.g.Stick,TIG,Gouge),theupperrightknobwillalwaysfunctionasanon/off
switch.

ThisparametercanonlybeaccessedusingPowerWaveManagersoftware.

P.502

Memory Change Lockout

Determinesifthememoriescanbeoverwrittenwithnewcontents.
Unlocked=Memoriescanbesavedandlimitscanbeconfigured(default).
FullyLocked=Memoriescannotbechanged-savingisprohibitedandlimitscan-
notbere-configured.AllowSavingWithinLimits=Allowssavingtomemorywhen
limitsareenabled.Onlythenominalvalueissavedandonlytotheselectedmemo-
ry.

ThisparametercanonlybeaccessedusingPowerWaveManagersoftware.

P.503

Memory Button Disable

Disablesthespecifiedmemorybutton(s).Whenamemoryisdisabled,weldingpro-
cedurescannotberestoredfromorsavedtothatmemory.Ifanattemptismadeto
saveorrestoreadisabledmemory,amessagewillbedisplayedonthelowerdis-
playindicatingthememorynumberisdisabled.Inmulti-headsystems,thisparame-
terdisablesthesamememorybuttonsonbothfeedheads.

ThisparametercanonlybeaccessedusingPowerWaveManagersoftware.

USER DEFINED PARAMETERS

Range

No,Yes
