Lincoln Electric IM10178 POWER FEED 84 U.I. CONTROL BOX User Manual
Page 68
B-32
OPERATION
POWER FEED 84, POWER FEED 84 DUAL
Parameter
Name and Description
P.81
Electrode Polarity
Thisoptionallowsselectionoftheelectrodevoltagesensepolarity.MostGMAWweldingprocedures
use Electrode Positive welding. Most GTAW and some inner shield procedures use Electrode
Negativewelding.
PositiveElectrodeWelding(default).
NegativeElectrodeWelding.
Ondual-headPowerFeed84Feeders,adifferentsettingcanbeusedforeachhead.Theoperator
willbepromptedtoselectwhichheadtoeditbeforethesettingcanbechanged.
P.82
Voltage Sense Display
AllowsviewingofVoltageSenseLeadSelectiontoaidintroubleshooting.Theconfigurationisdis-
playedasatextstringonthelowerdisplaywhenevertheoutputisenabled.Thisparameterisnot
savedonapowercycle,butwillberesettoFalse.
P.90
Retract Delay
ThisparameterisfortheWireRetractfunctionality.ItsetsthetimetheFeederwillwaitafteraweld
hasendedbeforeitstartsretractingwire.
Ondual-headPowerFeed84Feeders,adifferentsettingcanbeusedforeachhead.Theoperator
willbepromptedtoselectwhichheadtoeditbeforethesettingcanbechanged.
Note:Thisoptionmaynotbeavailableonallmachines.Theproductmustsupportthisfunctionality,
orthisoptionwillnotappearinthemenu.
P.92
Retract Adjust
ThisparameterisfortheWireRetractfunctionality.Itallowsanoperatortoadjusttheamounttime
theFeederwillretractthewireafteraweldhascompleted.Theadjustmentismadeasapercentage
oftheoriginaltime(-100%to100%)calculatedinternallybytheFeeder.
Ondual-headPowerFeed84Feeders,adifferentsettingcanbeusedforeachhead.Theoperator
willbepromptedtoselectwhichheadtoeditbeforethesettingcanbechanged.
Note:Thisoptionmaynotbeavailableonallmachines.Theproductmustsupportthisfunctionality,
orthisoptionwillnotappearinthemenu.
P.98
Disable Lockouts
Thisallowstheoperatortooverridealluserinterfacelockoutscurrentlyinplaceonthemachine.The
operatorwillbeaskedfortheUIpasscode,andifcorrect,alllockoutswillberemoved.Ifthelockouts
havebeenremovedwiththissetupmenuoption,thenthenameoftheoptionwillchangeto"Enable
Lockouts".Thelockoutscanbere-enabledwiththesamepasscodebyselectingthis.Themachine
willalsoautomaticallyre-enablelockoutsafter60-secondsofinactivity.
Note:ThisoptionwillonlydisplayifthereisaUIpasscodeonthemachine.
USER DEFINED PARAMETERS
Range
Positive
Electrode
Welding,
Negative
Electrode
Welding
n/a
