24

Plug Button

T10397-19

1

X X X

25

Circuit Breaker

T12287-8

1

X X X

26

Sealing Boot

S22061-2

1

X X X

27A

Solenoid Valve

M17294-8

1

X X X

27B

Plain Washer (Not Shown)

S9262-149

1

X X X

27C

Conduit Lock Nut (Not Shown)

T14370-1

1

X X X

28

Gas Hose (Not Shown)

T10642-265

1

X X X

29

Hose Clamp (Not Shown)

T13777-8

2

X X X

32

Bushing

T12380-3

1

X X X

33

Plug Button

T10397-7

1

X X X

39

Decal (M24810-3) (Part of M24810)

NSS

1

X X X

40

Decal (Rating) (M24810-4) (Part of M24810)

NSS

1

X X X

41

Decal (Gas) (M24810-5) (Part of M24810)

NSS

1

X X X

42

Decal (Circuit Breaker) (M24810-6) (Part of M24810)

NSS

1

X X X

45

USB P.C. Board Assembly (Codes 11988, 11990

S29868-[ ]

1

X X X

11994, 11997 & 11998 Only)

45A P.C. Board Standoff (Not Shown)

S29667

4

X X X

45B Sems Screw (Not Shown)

T10082-12

4

X X X

46A USB Receptacle & Connector Asbly (Codes 11988,

M24784-1

1

X X X

11990, 11994, 11997 & 11998)

46B Cap USB-A Jack (Codes 11988, 11990, 11994

M25060

1

X X X

11997 & 11998) (Not Shown)

46C Self Tapping Screw (Codes 11998, 11990, 11994

S8025-96

2

X X X

11997 & 11998) (Not Shown)

47A USB Panel Blank (Codes 11986, 11987, 11989

M24819

1

X X X

11991, 11993, 11996)

47B Self Tapping Screw (Codes 11986, 11987, 11989

S8025-121

2

X X X

11991, 11993, 11996) (Not Shown)

Jan-14

POWER FEED

®

84

Use only the parts marked “x” in the column under the
heading number called for in the model index page.

# Indicates a change this printing.

P-753-D.2

ITEM DESCRIPTION

PART NO.

QTY.

1 2 3 4 5 6 7 8 9

P-753-D.2

Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board

that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
