1A Wire Reel Stand (Std Duty) (Right and Left), Includes: K3342-1 1 X •
1A Wire Reel Stand (Hvy Duty) (Right and Left), Includes: K3343-1 1 • X
1C Mast Welded Assembly G7499 1 X •
1C Mast Welded Assembly G7584 1 • X
2 Outrigger L16322 1 X X
3A 1/4-20 SS Screw S24739-31 4 X X
3B 1/4-20 HLN T9187-16 4 X X
4A Bumper T14882-4 2 X X
4B Plain Washer S9262-27 2 X X
4C Thread Forming Screw S9225-100 2 X X
5 Lift Bail Final Assembly K3341-1 1 • X
6A Spindle Shaft M21542-2 1 X X
6B Plain Washer (Not Shown) S9262-120 2 X X
6C Lock Washer (Not Shown) E106A-4 2 X X
6D 3/8-16 x 1.25 HHCS CF000105 2 X X
7 Friction Washer S17435-3 4 X X
8 Spindle L10560-2 1 X X
9 Keyed Washer T12965-2 2 X X
10 Star Washer S27180 1 • X
11 Spring T11862-14 1 X X
12 Thumb Screw T14813-A 1 X X
13 Retaining Collar Assembly S23811 1 X X
Jan-14
POWER FEED ® 84 DuAL
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-746-J.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
