Lincoln Electric IM10178 POWER FEED 84 U.I. CONTROL BOX - Manual (Page 133)

Left Case Side & Decals Assembly, Includes: M24915 1 X *
Left Case Side & Decals Assembly, Includes: G7691-1 1 • X
1 Left Case Side G7487-1 1 X •
1A Left Case Side G7488-4 1 • X
1B LECO Logo Decal S27368-2 2 X •
1C LECO Logo Decal S11893-13 2 • X
1D Family Name Decal (M24857-1) (Part of M24857) NSS 1 X X
1E Family Name Decal (M24857-2) (Part of M24857) NSS 1 X X
1F Output Terminal Asbly S16656-4 1 • X
1G Thread Forming Screw (Not Shown) S9225-99 2 • X
1H Output Stud Cover M20007 1 • X
1J Output Stud Cover Plate S25669 1 • X
1K Thread Forming Screw S9225-68 2 • X
1L Output Terminal Decal (S29857-3) (Part of S29857) NSS 1 • X
1M Output Terminal Decal (S29857-4) (Part of S29857) NSS 1 • X
1N Thread Forming Screw (Not Shown) S9225-99 2 X X
2 Right Case Side & Decals Assembly, Includes: M24916 1 X X
2A Right Case Side G7488-1 1 X X
2B Decal (M24810-1) (Part of M24810) NSS 1 X X
2C Decal (M24810-2) (Part of M24810) NSS 1 X X
2D Family Name Decal (M24857-1) (Part of M24857) NSS 1 X X
2E Family Name Decal (M24857-2) (Part of M24857) NSS 1 X X
2F Thread Forming Screw (Not Shown) S9225-99 2 X X
3A Roof G7486-1 1 X X
3B Wire Drive P.C. Board S29867-[ ] 1 X X
3C #10-24 HLN (Not Shown) T9187-13 4 X X
3D Thread Forming Screw (Not Shown) S9225-99 4 X X
5 Warning Decal S20601-5 1 X X
Jan-14
POWER FEED ® 84
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-753-H.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-753-H.1
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
