1

Left Case Side & Decals Assembly, Includes:

M24949

1

X

1A

Left Case Side

G7487-2

1

X

1B

Family Name Decal

M24860-2

1

X

1C

Decal

M24951-2

1

X

1D Thread Forming Screw (Not Shown)

S9225-99

2

X

2

Right Case Side & Decals Assembly, Includes:

M24950

1

X

2A

Right Case Side

G7488-2

1

X

2B

Decal

M24951-1

1

X

2C

Family Name Decal

M24860-1

1

X

2D Thread Forming Screw

S9225-99

2

X

3A

Roof

G7486-2

1

X

3B

Wire Drive P.C. Board

S29867

2

X

3C #10-24 HLN

T9187-13

8

X

3D Thread Forming Screw (Not Shown)

S9225-99

4

X

5

Warning Decal

S20601-5

1

X

Jan-14

POWER FEED

®

84 DuAL

Use only the parts marked “x” in the column under the
heading number called for in the model index page.

# Indicates a change this printing.

P-746-h.1

ITEM DESCRIPTION

PART NO.

QTY.

1 2 3 4 5 6 7 8 9

P-746-h.1
