C-2

ACCESSORIES

POWER FEED 84, POWER FEED 84 DUAL

Cables

K#

K1543-xx

K2683-xx

Description

ControlCable:Male5pintoFemale5
pinArcLinkcable.

HeavyDutyControlCable:Male5pin
toFemale5pinArcLinkcable

Purpose

Connectstheuserinterfacetothe
wiredriveforboomsystems.
Connectsthewiredrivetothepower
sourceonbenchsystems.

Connectstheuserinterfacetothe
wiredriveforboomsystems.
Connectsthewiredrivetothepower
sourceonbenchsystems.

general aCCessories

K#

K1546-1

K1546-2

K1733-1

K590-6

K283

K3341-1

K4068-1


Description

IncomingBushingforLincolnConduit.

IncomingBushingforLincolnConduit.

WireStraightener.

WaterConnectionKit.

PortableDigitalWireFeedSpeedMeter.

LiftBail.

CartMountingBracket

Purpose

Usewith.025–1/16”wires.

Usewith1/16”to1/8”wires.

UsedtomountfeederstoK3059-2
andK3059-3carts.

gun adaPter Kits

K#

K3344-1

K3345-1

K3346-1

K3347-1

K3348-1

K3349-1

Description

GunAdapterKit,LincolnBack-end
AlsoIncludesKP4069-1GuidetubeKit.

GunAdapterKit,Tweco#2-#4back-end

GunAdapterKit,Tweco#5back-end

GunAdapterKit,Millerback-end

GunAdapterKit,Oxoback-end
AlsoIncludesKP4069-1Guidetubekit.

GunAdapterKit,Fast-Mate(Euro)
AlsoincludesKP4069-3Guidetubekit.
