Wire Drive Door, Right, Includes:

L10193-9

1

X

1

Door Machining

L10092-4

1

X

2

Pin

M8809-135

4

X

3

Decal

S22900-1

1

X

4

Pressure Arm

M18183-3

2

X

5

Wear Plug

S22734

2

X

6

Spring Retaining Rod

S22662

1

X

7

Compression Spring

T11862-54

2

X

8

#6-32 x 1.00 SHCS (Not Shown)

T9447-100

2

X

9

Indicator

S22899

1

X

10

Plastic Thrust Washer

T14052

4

X

11

Thrust Washer

T14043

1

X

12

Adjustment Knob

S22674

1

X

13

Door Insert

G7593

1

X

14

Thread Forming Screw

S9225-99

1

X

15

Warning Decal

S25815-1

1

X

Wire Drive Door, Left, Includes:

L10193-10

1

X

1

Door Machining

L10092-4

1

X

2

Pin

M8809-135

4

X

3

Decal

S22900-1

1

X

4

Pressure Arm

M18183-3

2

X

5

Wear Plug

S22734

2

X

6

Spring Retaining Rod

S22662

1

X

7

Compression Spring

T11862-54

2

X

8

#6-32 x 1.00 SHCS (Not Shown)

T9447-100

2

X

9

Indicator

S22899

1

X

10

Plastic Thrust Washer

T14052

4

X

11

Thrust Washer

T14043

1

X

12

Adjustment Knob

S22674

1

X

13

Door Insert

G7593

1

X

14

Thread Forming Screw

S9225-99

1

X

15

Warning Decal

S25815-1

1

X

Jan-14

POWER FEED

®

84 DuAL

Use only the parts marked “x” in the column under the
heading number called for in the model index page.

# Indicates a change this printing.

P-746-G.1

ITEM DESCRIPTION

PART NO.

QTY.

1 2 3 4 5 6 7 8 9

P-746-G.1
