Control Box Assembly, Includes:

K3336-1

1

X • •

Control Box Assembly, Includes:

K3336-2

1

• X •

Control Box Assembly, Includes:

K3336-3

1

• • X

1

Power Feed 894 UI Case Front

G7544-1

1

X X X

2A

Harness Assembly

M22256-2

1

X X X

2B

Self Tapping Screw

S8025-96

4

X X X

3

Harness Assembly, Includes:

M24853-1

2

X X X

3A

Connector (5 Socket) (P13)

S12021-73

2

X X X

3B

Self Tapping Screw

S8025-96

8

X X X

4A

USB Receptacle & Connector Assembly

M24784-1

1

• X •

4B

Cap USB-A Jack

M25060

1

• X •

5

USB Blank Panel

M24819

1

X • X

6

Self Tapping Screw (Not Shown)

S8025-121

2

X • X

Self Tapping Screw (Not Shown)

S8025-96

2

• X •

7

#10-24 HN

CF000010

4

X X X

8

Lock Washer

E106A-1

2

X X X

10A

UI Case Back

G7543

1

X X X

10B

Thread Forming Screw

S9225-99

6

X X X

11A

USB P.C. Board Assembly

S29868-[ ]

1

• X •

11B

Sems Screw (Not Shown)

T10082-12

4

• X •

12

Momentary Rocker Switch

T10800-76

1

X X X

13

Plug & Lead Assembly (P32) (Not Shown)

S18250-1020

1

X X X

14

Plug & Lead Assembly (P1, P31) (Not Shown)

S18250-1022

1

• X •

15

Plug & Lead Assembly (P2, J31) (Not Shown)

S18250-1023

1

• X •

16

Cold Feed/Gas Purge Decal

S29826

1

X X X

17

UI Trim

G6529-1

1

X X X

18A

User Interface, Power Feed 84

G7613

1

X X •

18A

User Interface, Power Feed 84

G7501-2

1

• • X

18B

Thread Forming Screw (Not Shown)

S9225-99

4

X X X

19

Family Name/Lincoln Logo Decal

M24868

1

X X X

20

Warning Decal

M16196

1

X X X

Oct-13

POweR Feed 84 U.I. COnTROL BOx

Use only the parts marked “x” in the column under the
heading number called for in the model index page.

# Indicates a change this printing.

P-745-C.1

ITeM deSCRIPTIOn

PART nO.

QTY.

1 2 3 4 5 6 7 8 9

P-745-C.1

note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board

that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
