B-31

OPERATION

POWER FEED 84, POWER FEED 84 DUAL

Parameter

Name and Description

P.28

Display Workpoint as Amps Option

Thisoptiondetermineshowworkpointisdisplayed.
False=The workpoint is displayed in the format defined in the weld set

(default).

True=Allworkpointvaluesaredisplayedasanamperage.

Note:Thisoptionmaynotbeavailableonallmachines.Thepowersource
mustsupportthisfunctionality,orthisoptionwillnotappearinthemenu.

P.37

USB Memories

Allows operator to scroll through files on a mounted USB drive in the
"\Lincoln\Memories"folder,iffilesexistinthatfolder.Theoperatorcanthen
chooseafile,andifitisavalidmemorysetfile,thememoriesstoredinthat
filewillbeloadedtotheusermemoriesoftheselectedhead.Theoperator
willbeinformedofsuccessorfailurebyamessageontheUserInterface.

Note:Thisoptionwillonlyappearinthemenuif(1)aUSBmoduleisinthe
samegroupastheUIand(2)aUSBdrivehasbeenpluggedintotheUSB
portandwasproperlymounted.

P.38

Save Memories to USB

Allowsoperatortosavetheusermemoriesofthecurrentlyselectedhead
toamountedUSBdrive.Thefilenamewillbeautomaticallygeneratedand
savedintothe"Lincoln\Memories\"folderontheUSBdrive.Ifthedirectory
doesnotexist,itwillbecreated.

Note:Thisoptionwillonlyappearinthemenuif(1)aUSBmoduleisinthe
samegroupastheUIand(2)aUSBdrivehasbeenpluggedintotheUSB
portandwasproperlymounted.

P.41

WFS Offset

Allows the operator to adjust the speed of the WD drive rolls. The adjust-
mentcanrangefrom-5%to+5%ofnormalspeed.

Ondual-headPowerFeed84Feeders,adifferentsettingcanbeusedfor
each head. The operator will be prompted to select which head to edit
beforethesettingcanbechanged.

Note: This option may not be available on all machines. The wire drive
mustsupportthisfunctionality,orthisoptionwillnotappearinthemenu.

P.80

Sense From Studs

Use this option for diagnostic purposes only. When power is cycled, this
optionisautomaticallyresettoFalse.
False=Voltage sensing is automatically determined by the selected weld

modeandothermachinesettings(default).

True=Voltagesensingisforcedto"studs".

USER DEFINED PARAMETERS

Range

False,True

Don'tuse

memory

File1

File2

...

LastFile

n/a

-5%to5%

(defaultis0%)

False,

True
